1 11
Power
500W
Torque
65Nm
Range
80+ km
Top Speed
32km/h
Payload
280lbs

VOLTBIKE

Elegant V2

Elegant V2

Elegant V2 has the head turning design with fully integrated battery and effortless step through frame. Thoughtfully designed with optimal beauty and selection of premium components. Offering a long range battery and powerful rear-hub motor.

This model has all the great features of the Elegant but with a stylish redesigned frame which features a larger step-thru area for easier mounting.

For more info on our V2 Bikes and how they vary from the Classic models, see our Blog Post about the VoltBike V2 models.

In-stock and ships in 2 business days.
Elegant V2 in Pink is out of stock.
$1,949.00 CAD
$2,449.00 CAD $1,949.00 CAD
Sale Sold out
Bicycle Color
  • Free Shipping
  • 1 Year Warranty
  • 20+ Quality Standards Checklist
View full details

Overview

500W Rated Power

The Elegant V2 is using a Bafang G07 series geared motor which provides 65 N.m. max torque and 500w rated power. The Bafang G07 series is remarkable for its high efficiency and power thanks to the integrated nylon planetary gears.

Fully Integrated Battery

The Elegant V2 is using 48v 17.5Ah fully integrated battery pack with Samsung INR18650-35E cells. The integrated frame design gives you security in various weather conditions plus offering unmatched visual appearance. Samsung SDI’s Li-ion battery cells are preferred by high-end e-bike makers and companies that lead the e-bike market.

Extra Smooth Ride

Voltbike Elegant V2 comes standard with lockout suspension Suntour XCT DS. Designed for quick release axles and bolt on axles. 135mm dropout, 32mm stanchions, 210mm steerer tube, 90mm travel. Weight is only 7lbs.

Sturdy Rear Rack

Standard for Elegant V2 is an aluminum rear rack which can fit any load with ease up to 50lbs. Mounted directly on the rack is LED rear taillight with brake light functionality.

Backlit Color Display

Large practical display located in the middle of the handlebar offers real time stats such as speed, pedal assist level, battery capacity, distance traveled and current load. You can also charge your cell phone through the built-in USB connector. New for the display is the lighting sensor which atomically activates your lights when it gets dark.

Hydraulic Stopping Power

Voltbike Elegant V2 is using Tektro Auriga hydraulic front and rear disc brakes with 180mm rotors. Tektro Auriga comp disc brakes features an open system design using non-corrosive and environment-friendly mineral oil. Features dual piston design, melt forged caliper body with automatic positioning via front or rear adapters.

Adjust Your Ride

Adjust your bike as per your need. No matter what your style of riding, VoltBike has a stem with the fit, performance and style you're looking. VoltBike is using stem Promax MA-570 with adjustable angle 35° - 145° and 108mm extension.

Simple Controls

Our redesigned cockpit includes large easy to read color LCD screen which shows all the important information like speed, battery level and current load. Get instant power with the integrated half-twist throttle with and on/off button which helps prevent accidental activation.

Parts Included

Our bikes ship 95% assembled with everything you’ll need to get up and running, including:

Specifications

  • Weight 61.0 lb
  • Battery 48V Li-ion 17.5Ah Samsung (840Wh)
  • Battery Style Internal
  • Bottom Bracket Sealed cartridge Neco 910, 23.5mm + 120mm + 23.5mm
  • Brakes Hydraulic disc brakes front/rear Tektro Auriga HD-E500
  • Brake Lever Tektro with integrated bell
  • Chain KMC Rust Buster
  • Crankset Aluminum Alloy-6061 38T Crank, 170mm with Outer Guard
  • Derailleur Guard Rear Metal Derailleur Guard
  • Fork Suntour XCT DS suspension fork with preload adjuster
  • Frame Type Step-Through
  • Freewheel Cassette Sunrace M2 Freewheel Super-Low 7 Speed 13-34T
  • Handlebars PROMAX ALLUMINUM ALLOY 31.8mm*22.2mm*680mm, 9 degree
  • Hubset Alloy 6061 Electric Motor
  • Motor 48V 500W Bafang G070 Hub Motor
  • Motor Type Hub Motor
  • Pedals Wellgo M-248DU
  • Rear Derailleur Shimano Acera RD-410 7 speed direct rear derailleur
  • Rider Max Weight {"value":280.0,"unit":"lb"}
  • Rims 26" with 36 spokes
  • Seat Velo Plush VL-6142
  • Seat Post Promax SP-252 Aluminum 6061 Alloy, 30.4mm*350mm
  • Shifter Type Shimano Tourney TX50R6CT Thumb Shifter Plus 7-Speed
  • Spokes Rear 13G, Front 13G
  • Stem Adjustable stem Promax MA-579 with extension 110mm. Adjustable angles 90° - 160°. Aluminum alloy.
  • Tires Kenda 26"x2.1"

Sizing

  • aFrame Size: 18"
  • bStand-over Height: 22"
  • cReach: 17"
  • dTop-tube Length: 22"
  • eHandlebar Height: 41.5"-43.5"
  • fSeat Height: 32"-39"
  • gWheel Size: ⌀26"x2"
  • hWheelbase: 44.5"
  • iLength: 69"
Elegant V2 sizing chart.
